HE97300LL-16,16 Points,7.5KW,PLC Valve-Controlled Synchronous Lifting System
The HELL PLC Valve-Controlled Synchronous Lifting System, engineered by ULTPRE, delivers precision control and efficiency for heavy-load lifting applications. Equipped with a 10-inch touchscreen and an open-parameter interface, it offers customizable settings for seamless operation. Powered by a Siemens processing and analog module, the system ensures reliable data analysis and real-time adjustments.
Description
Model: HE97300LL-16 | Series:HELL | Product Line: Industrial Tools
Key Features:
-
High-protection PLC electrical cabinet with optional wireless remote touchscreen.
-
20m/30m displacement sensor cables for flexible installation.
-
Advanced functions: Sensor parameter setup, pre-lift pressure adjustment, overload/sensor-loss/error alarms, and synchronized lifting/descent modes.
-
Clear panel labeling for hoses, sensors, and cylinder ports to streamline connections.
Built for durability and adaptability, the HELL system guarantees safety and precision in bridge construction, industrial maintenance, and infrastructure projects.
Specifications
| Maximum Operating Pressure (bar) | 700 |
| Motor Power(KW) | 7.5 |
| Usable Oil (L) | 300 |
| Points | 16 |
| Voltage(VAC) | 380/440/660 |
| Displacement Sensors Measure Range(mm) | 1000 |
| Sensor Cable Length(M) | 30 |
| Functions | Pre-Jacking/Sync-Lifting/Sync-Lowering |
Hydraulic Diagram
Hydraulic Diagram
Series Comparison
| Model | Max Working Pressure(Mpa) | Points | Motor Power(KW) | High Pressure Oil Flow Rate(L/Min) | Voltage(VAC) | Phase | Usable Oil(L) | Displacement Sensor Range(mm) | Sensor Cable Length(M) | Function |
|---|---|---|---|---|---|---|---|---|---|---|
| HE5060LL-4 | 70 | 4 | 1.5 | 1 | 230 | 1 | 60 | 1000 | 30 | Pre-Jacking/Sync-Lifting/Sync-Lowering |
| HE7080LL-4 | 70 | 4 | 2.2 | 1.5 | 380/230 | 3 | 80 | 1000 | 30 | Pre-Jacking/Sync-Lifting/Sync-Lowering |
| HE84120LL-4 | 70 | 4 | 4 | 2.3 | 380/440/660 | 3 | 120 | 1000 | 30 | Pre-Jacking/Sync-Lifting/Sync-Lowering |
| HE97150LL-4 | 70 | 4 | 7.5 | 4.2 | 380/440/660 | 3 | 150 | 1000 | 30 | Pre-Jacking/Sync-Lifting/Sync-Lowering |
| HE84150LL-8 | 70 | 8 | 4 | 2.3 | 380/440/660 | 3 | 150 | 1000 | 30 | Pre-Jacking/Sync-Lifting/Sync-Lowering |
| HE97200LL-8 | 70 | 8 | 7.5 | 4.2 | 380/440/660 | 3 | 200 | 1000 | 30 | Pre-Jacking/Sync-Lifting/Sync-Lowering |
| HE97300LL-16 | 70 | 16 | 7.5 | 4.2 | 380/440/660 | 3 | 300 | 1000 | 30 | Pre-Jacking/Sync-Lifting/Sync-Lowering |
| HE70100LL-8-2 | 70 | 16 | 2.2X2 | 1.5X2 | 380/230 | 3 | 100X2 | 1000 | 30 | 2 Sets 8 Point System Connected Together Or Work Individually |
| HE84200LL-8-3 | 70 | 24 | 4X3 | 2.3X3 | 380/440/660 | 3 | 200X3 | 1000 | 30 | 3 Sets 8 Point System Connected Together Or Work Individually |
Downloads
| – | File Name | File Type |
|---|---|---|
 | PLC Servo Synchronous Hydraulic System Brochure | English |
| PLC阀控同步顶升系统图册 | 中文 |
| Synchronous Lifting System User Manual | English |
| 8点同步顶升系统使用说明书 | 中文 |
| SYNC System Quick Guide | English |
