HSL500-300, 500 Ton Capacity,300mm Stroke, Single Acting Spring Retraction Hydraulic Lock Nut Cylinders

ULTPRE’s HSL Series represents a high-performance range of single-acting spring-return hydraulic cylinders with an integrated nut-locking mechanism. Designed for precision, safety, and durability, these cylinders are ideal for applications requiring reliable load holding and smooth operation under challenging conditions.

PRICE ON REQUEST

Features

Description

Series: HSL | Product Line: Industrial Tools

Single-Acting with Spring Return

Provides efficient spring-assisted retraction for consistent and rapid cycle completion.
Spherical Saddle Design

Equipped with a spherical saddle to significantly improve misalignment resistance, ensuring stable and aligned operation.
Mechanical Locking Nut for Load Holding

Features a lock nut mechanism that securely maintains load position without the need for continuous hydraulic pressure, enhancing safety and energy efficiency.
Low-Friction Locking Nut

Engineered for easy manual operation, reducing effort and saving time during adjustment and locking.
10% Misalignment Tolerance at 90% Stroke

Capable of handling up to 10% misalignment at 90% of maximum stroke, offering flexibility in demanding applications.
Overflow Port as Stroke Limiter

Includes an overflow port that acts as a stroke limiter, preventing piston overtravel and protecting the cylinder from damage.
High-Grade Polyurethane Seals

Utilizes premium polyurethane seals for excellent leakage prevention, wear resistance, and extended service life.
Certified G80 Lifting Eye and Base Mounting Holes

Comes standard with a certified G80 high-strength lifting eye and base mounting holes for safe handling and versatile installation.
Advanced NAC Surface Treatment

All components undergo NAC surface treatment—gas nitriding and post-oxidation—for superior corrosion resistance and enhanced performance under misalignment loads.

Applications:

Ideal for use in industrial machinery, lifting systems, mobile equipment, automation, and any application where secure load holding, misalignment compensation, and compact hydraulic actuation are critical.

Design

Equipped with a spherical saddle,it effectively enhances the anti-overload capability of the hydraulic cylinder
The nut can be easily disassembled and tightened by punching a hole in it.
The exhaust port expels air,preventing air resistance from causing jerky motion and noise,and ensuring stable operation of the hydraulic system.
CEJN connector from Sweden and dust cap for consistent safety.
The nut ensures mechanical locking when the load is maintained.
G80 high-strength lifting rings
Dust seal, preventing external impuritiesfrom entering the interior of the cylinder and causing contamination or damage.
Composite support ring to prevent metal-to-metal contact, reducing over-load issues and extending cylinder service life.
High-pressure seal to achieve zero internal leakage in the hydraulic system, reducing wear and extending service life.
Powerful spring for rapid returnstroke.

Specifications

Maximum Operating Pressure (bar)	700
Capacity Class (tonnage)	500
Stroke (mm)	300
Collapsed Height/mm	467
Extended Height/mm	767
Return Type	Single-Acting, Spring Return
Cylinder Effective(cm²)	730.6
Oil Capacity(cm³)	21918
Surface Treatment	NAC surface treatment, gas nitriding and post-oxidation surface treatment
Coupler	CEJN 3/8NPT-18
Weight (kg)	445

Dimensions

Collapsed Height/mm(A)	467
Extended Height/mm(B)	767
Cylinder Outside Dia/mm(C)	400
Cylinder Inner Dia/mm(D)	305
Plunger Dia/mm(E)	Tr305x6
Base To Advance Port/mm(F)	49
Saddle Dia/mm(H)	290
Saddle Protri. From Plgr./mm(J)	10
Max Saddle Tilt Angle	3°
Lock Nut Height/mm(Q)	61.5

Series Comparison

Model Number	Capacity/Ton（kN)	Stroke/mm	Cylinder Effective Area/cm2	Oil Capacity/cm3	Collapsed Height/mm(A)	Extended Height/mm(B)	Cylinder Outside Dia/mm(C)	Cylinder Inner Dia/mm(D)	Plunger Dia/mm(E)	Base To Advance Port/mm(F)	Saddle Dia/mm(H)	Saddle Protri. From Plgr./mm(J)	Max Saddle Tilt Angle	Lock Nut Height Q (mm)	Weight/Kg
HSL30-50	30（309）	50	44.2	221	120	170	110	75	Tr75x4	19	65	5	5°	25	10
HSL30-100		100	44.2	442	170	270	110	75	Tr75x4	19	65	5	5°	25	14
HSL30-150		150	44.2	663	225	375	110	75	Tr75x4	19	65	5	5°	25	17
HSL30-200		200	44.2	884	280	480	110	75	Tr75x4	19	65	5	5°	25	21
HSL30-250		250	44.2	1105	335	585	110	75	Tr75x4	19	65	5	5°	25	25
HSL30-300		300	44.2	1326	390	690	110	75	Tr75x4	19	65	5	5°	25	29
HSL60-50	60（606）	50	86.6	433	126	176	140	105	Tr105x4	19	96	7	5°	28	15
HSL60-100		100	86.6	866	176	276	140	105	Tr105x4	19	96	7	5°	28	20
HSL60-150		150	86.6	1299	231	381	140	105	Tr105x4	19	96	7	5°	28	27
HSL60-200		200	86.6	1732	286	486	140	105	Tr105x4	19	96	7	5°	28	33
HSL60-250		250	86.6	2165	341	591	140	105	Tr105x4	19	96	7	5°	28	39
HSL60-300		300	86.6	2598	396	696	140	105	Tr105x4	19	96	7	5°	28	46
HSL100-50	100（1002）	50	146.8	734	137	187	173	135	Tr135x6	21	126	8	5°	31	25
HSL100-100		100	146.8	1468	187	287	173	135	Tr135x6	21	126	8	5°	31	34
HSL100-150		150	146.8	2202	242	392	173	135	Tr135x6	21	126	8	5°	31	43
HSL100-200		200	146.8	2936	297	497	173	135	Tr135x6	21	126	8	5°	31	53
HSL100-250		250	146.8	3670	352	602	173	135	Tr135x6	21	126	8	5°	31	63
HSL100-300		300	146.8	4404	407	707	173	135	Tr135x6	21	126	8	5°	31	73
HSL160-45	160（1589）	45	231.3	1041	148	193	220	170	Tr170x6	27	160	9	5°	40	43
HSL160-100		100	231.3	2313	203	303	220	170	Tr170x6	27	160	9	5°	40	58
HSL160-150		150	231.3	3470	258	408	220	170	Tr170x6	27	160	9	5°	40	74
HSL160-200		200	231.3	4626	313	513	220	170	Tr170x6	27	160	9	5°	40	90
HSL160-250		250	231.3	5783	368	618	220	170	Tr170x6	27	160	9	5°	40	106
HSL160-300		300	231.3	6939	423	723	220	170	Tr170x6	27	160	9	5°	40	122
HSL200-45	200（1985）	45	285.6	1285	155	200	245	190	Tr190x6	30	180	10	5°	43	53
HSL200-100		100	285.6	2856	210	310	245	190	Tr190x6	30	180	10	5°	43	72
HSL200-150		150	285.6	4284	265	415	245	190	Tr190x6	30	180	10	5°	43	90
HSL200-200		200	285.6	5712	320	520	245	190	Tr190x6	30	180	10	5°	43	109
HSL200-250		250	285.6	7140	375	625	245	190	Tr190x6	30	180	10	5°	43	128
HSL200-300		300	285.6	8568	430	730	245	190	Tr190x6	30	180	10	5°	43	147
HSL250-45	250（2541）	45	366.8	1651	159	204	275	215	Tr215x6	32	200	12	5°	43	68
HSL250-100		100	366.8	3668	214	314	275	215	Tr215x6	32	200	12	5°	43	92
HSL250-150		150	366.8	5502	269	419	275	215	Tr215x6	32	200	12	5°	43	116
HSL250-200		200	366.8	7336	324	524	275	215	Tr215x6	32	200	12	5°	43	141
HSL250-250		250	366.8	9170	379	629	275	215	Tr215x6	32	200	12	5°	43	165
HSL250-300		300	366.8	11004	434	734	275	215	Tr215x6	32	200	12	5°	43	189
HSL300-45	300（3036）	45	433.7	1952	166	211	305	235	Tr235x6	35	225	12	4°	48	90
HSL300-100		100	433.7	4337	221	321	305	235	Tr235x6	35	225	12	4°	48	120
HSL300-150		150	433.7	6506	276	426	305	235	Tr235x6	35	225	12	4°	48	151
HSL300-200		200	433.7	8674	331	531	305	235	Tr235x6	35	225	12	4°	48	181
HSL300-250		250	433.7	10843	386	636	305	235	Tr235x6	35	225	12	4°	48	211
HSL300-300		300	433.7	13011	441	741	305	235	Tr235x6	35	225	12	4°	48	241
HSL400-45	400（4008）	45	559.5	2518	178	223	350	270	Tr270x6	40	250	12	4°	55	127
HSL400-100		100	559.5	5595	233	333	350	270	Tr270x6	40	250	12	4°	55	167
HSL400-150		150	559.5	8393	288	438	350	270	Tr270x6	40	250	12	4°	55	207
HSL400-200		200	559.5	11190	343	543	350	270	Tr270x6	40	250	12	4°	55	247
HSL400-250		250	559.5	13988	398	648	350	270	Tr270x6	40	250	12	4°	55	288
HSL400-300		300	559.5	16785	453	753	350	270	Tr270x6	40	250	12	4°	55	328
HSL500-45	500（5114）	45	730.6	3288	192	237	400	305	Tr305x6	49	290	10	3°	61.5	181
HSL500-100		100	730.6	7306	247	347	400	305	Tr305x6	49	290	10	3°	61.5	234
HSL500-150		150	730.6	10959	302	452	400	305	Tr305x6	49	290	10	3°	61.5	287
HSL500-200		200	730.6	14612	357	557	400	305	Tr305x6	49	290	10	3°	61.5	339
HSL500-250		250	730.6	18265	412	662	400	305	Tr305x6	49	290	10	3°	61.5	392
HSL500-300		300	730.6	21918	467	767	400	305	Tr305x6	49	290	10	3°	61.5	445
