HRC5010, 50 Ton Capacity,260mm Stroke, Single Acting Spring Retraction Hydraulic Cylinders

ULTPRE’s HRC Series is a versatile range of single-acting hydraulic cylinders engineered for high performance, durability, and ease of use across various applications. Designed with precision and reliability in mind, these cylinders deliver exceptional functionality even under demanding conditions.

PRICE ON REQUEST
Download Catalogue

Series: HRC | Product Line: Industrial Tools

  • Reinforced Stop Ring
    A robustly designed stop ring enhances durability and withstands misalignment loads, ensuring long-term operational stability.

  • Certified G80 High-Strength Lifting Eye
    Equipped with a certified G80 high-strength lifting eye for safe and reliable handling and installation.

  • Base Mounting Holes Standard Across All Models
    All cylinders come with standard base mounting holes for simplified and flexible installation.

  • Integrated Bleed Valve
    Features a built-in bleed valve for smooth extension and rapid retraction, optimizing cycle times and performance.

  • Pre-Tensioned Spring System
    The pre-tensioned spring mechanism enables faster piston retraction, improving efficiency in repetitive operations.

  • High-Grade Polyurethane Seals
    Engineered with premium polyurethane seals for superior leak-proof performance, exceptional wear resistance, and extended service life.

  • Piston Wiper Ring
    Reduces contamination ingress, minimizing maintenance needs and prolonging the cylinder’s lifespan.

  • Versatile Connection Options
    Pre-machined external thread rings, piston threads, and base mounting holes offer effortless integration and mounting.

  • Multi-Position Installation
    Suitable for use in any mounting orientation or direction, providing adaptability to diverse application requirements.

  • Advanced NAC Surface Treatment
    All components undergo NAC surface treatment, gas nitriding and post-oxidation surface treatment, for outstanding corrosion resistance and enhanced load tolerance under misalignment.

Applications:
Ideal for industrial automation, material handling, construction machinery, agricultural equipment, and other fields requiring reliable and efficient linear actuation.

Experience the ULTPRE Advantage
With superior engineering, premium materials, and user-centric design, the HRC Series ensures unmatched performance and durability. Choose ULTPRE for hydraulic solutions that empower your operations.

  • Removable hardsaddle to prevent damage tothe piston when in contact with rough surfaces.
  • Stop ring for absorbing overload and preventing piston overtravel.
  • Exhaust port to expel air, preventing air resistance from causing jerky motion and noise, ensuring stable operation of the hydraulic system.
  • CEJN connector from Sweden and dust cap for consistent safety.
  • Dust seal, preventing external impurities from entering the interior of the cylinder and causing contamination or damage.
  • Powerful spring for rapid return stroke.
  • High-pressure seal to achieve zero internal leakage in the hydraulic system, reducing wear and extending service life.
Maximum Operating Pressure (bar)700
Capacity Class (tonnage)50
Stroke (mm)260
Collapsed Height/mm384
Extended Height/mm644
Return TypeSingle-Acting, Spring Return
Cylinder Effective(cm2)71.3
Oil Capacity(cm3)1855
Surface TreatmentNAC surface treatment, gas nitriding and post-oxidation surface treatment
CouplerCEJN 3/8NPT-18
Weight (kg)31.8
Collapsed Height/mm(A)384
Extended Height/mm(B)644
Cylinder Outside Dia/mm(D)127
Cylinder Inner Dia/mm(E)95.2
Plunger Dia/mm(F)79.4
Base To Advance Port/mm(H)33
Saddle Dia/mm(J)71
Saddle Protri. From Plgr./mm(K)2
Piston Internal Thread(O)*
Piston Thread Length/mm(P)*
Model NumberCapacity/Ton（kN)Stroke/mmCylinder Effective Area/cm2Oil Capacity/cm3Collapsed Height/mm(A)Extended Height/mm(B)Cylinder Outside Dia/mm(D)Cylinder Inner Dia/mm(E)Plunger Dia/mm(F)Base To Advance Port/mm(H)Saddle Dia/mm(J)Saddle Protri. From Plgr./mm(K)Piston Internal Thread(O)Piston Thread Length/mm(P)Base Mounting Hole Bolt Circle/mm(U)Base Mounting Hole Thread(V)Base Mounting Hole Thread Length/mm(Z)Collar Thread(W)Collar Thread Length/mm(X)Weight/Kg
HRC505(45)166.41041575828.625.419****295.6mm***1
HRC5125161101353828.625.4192563/4”-16UN14251/4”-20UNC141 1/2”-16UN281
HRC5379501652443828.625.4192563/4”-16UN14251/4”-20UNC141 1/2”-16UN281.5
HRC55127832163433828.625.4192563/4”-16UN14251/4”-20UNC141 1/2”-16UN281.9
HRC571771152734503828.625.4192563/4”-16UN16251/4”-20UNC141 1/2”-16UN282.4
HRC592321513245563828.625.4192563/4”-16UN16251/4”-20UNC141 1/2”-16UN282.8
HRC10110(101)2614.438901165742.838.119**#10 – 24 UN6405/16”-18UNC122 1/4”-14UN271.8
HRC10254781211755742.838.1193561”-8UN19405/16”-18UNC122 1/4”-14UN272.3
HRC1041051521712765742.838.1193561”-8UN19405/16”-18UNC122 1/4”-14UN273.3
HRC1061562262484045742.838.1193561”-8UN19405/16”-18UNC122 1/4”-14UN274.4
HRC1082032942985015742.838.1193561”-8UN19405/16”-18UNC122 1/4”-14UN275.4
HRC10102573733496065742.838.1193561”-8UN19405/16”-18UNC122 1/4”-14UN276.4
HRC10123044414007045742.838.1193561”-8UN19405/16”-18UNC122 1/4”-14UN276.8
HRC10143565164518075742.838.1193561”-8UN19405/16”-18UNC122 1/4”-14UN278.2
HRC15115(142)2520.3511241497050.841.3193891”-8UN25483/8”-16UNC122 3/4”-16UN303.3
HRC152511041492007050.841.3193891”-8UN25483/8”-16UNC122 3/4”-16UN304.1
HRC1541012052003017050.841.3193891”-8UN25483/8”-16UNC122 3/4”-16UN305
HRC1561523082714237050.841.3253891”-8UN25483/8”-16UNC122 3/4”-16UN306.8
HRC1582034113225257050.841.3253891”-8UN25483/8”-16UNC122 3/4”-16UN308.2
HRC15102545163736277050.841.3253891”-8UN25483/8”-16UNC122 3/4”-16UN309.5
HRC15123056194247297050.841.3253891”-8UN25483/8”-16UNC122 3/4”-16UN3010.9
HRC15143567234758317050.841.3253891”-8UN25483/8”-16UNC122 3/4”-16UN3011.8
HRC25125(232)2633.3861401668665.157.22551101 1/2”-16UN25591/2”-13UNC193 5/16”-12UN495.9
HRC252501661652158665.157.22551101 1/2”-16UN25591/2”-13UNC193 5/16”-12UN496.4
HRC2541023392163188665.157.22551101 1/2”-16UN25591/2”-13UNC193 5/16”-12UN498.2
HRC2561585252734318665.157.22551101 1/2”-16UN25591/2”-13UNC193 5/16”-12UN4910
HRC2582106973245348665.157.22551101 1/2”-16UN25591/2”-13UNC193 5/16”-12UN4912.2
HRC25102618673756368665.157.22551101 1/2”-16UN25591/2”-13UNC193 5/16”-12UN4914.1
HRC251231110334257368665.157.22551101 1/2”-16UN25591/2”-13UNC193 5/16”-12UN4916.3
HRC251436212024768388665.157.22551101 1/2”-16UN25591/2”-13UNC193 5/16”-12UN4917.7
HRC30830(295)20942.98803875961027357.22951101 1/2”-16UN25591/2”-13UNC163 5/16”-12UN4918.1
HRC50250(498)5171.336217622712795.279.433712**951/2”-13UNC195”-12UN5515
HRC50410171922732812795.279.433712**951/2”-13UNC195”-12UN5519.1
HRC506159113128344212795.279.435712**951/2”-13UNC195”-12UN5523.1
HRC5010260185538464412795.279.435712**951/2”-13UNC195”-12UN5531.8
HRC5013337239946079712795.279.435712**951/2”-13UNC195”-12UN5537.6
HRC75675(718)156102.61601286442146114.395.330712**1141/2”-13UNC165 3/4”-12UN4429.5
HRC75133333417492825146114.395.330712**1141/2”-13UNC165 3/4”-12UN4459
HRC100295(933)51133.1676219270178130.2104.841712**1403/4”-10UNC256 7/8”-12UN4436.7
HRC10061682239357525178130.2104.841712**1403/4”-10UNC256 7/8”-12UN4459
HRC100102603466449709178130.2104.841712**1403/4”-10UNC256 7/8”-12UN4472.6
