EHP-310，3 Jaw,10 Ton, Safety-Cage Hydraulic Puller
The EHP Safety-Cage Hydraulic Puller Series from ULTPRE revolutionizes heavy-duty component removal with robust engineering and operator-focused design. Featuring a secure cage-style jaw structure, it ensures maximum safety by preventing component ejection during high-force operations.
Description
Model: EHP-310 | Series: EPH | Product Line: Industrial Tools
Key Features:
-
Powerful hydraulic system enables effortless disassembly of large, stubborn parts.
-
One-person operation with enhanced efficiency for rapid pulling tasks.
-
Steel cage framework provides superior protection against flying debris.
-
Proportional control for smooth, precise force application.
Built to withstand extreme loads while prioritizing operator safety, the EHP series combines ULTPRE’s signature durability with intuitive functionality.
Specifications
| Maximum Operating Pressure (bar) | 700 |
| Capacity(Ton) | 10 |
| Number of Jaws | 3 |
| Spread(mm) | 19-304 |
| Max Reach(mm) | 203 |
| Stroke(mm) | 152 |
| Weight(Kg) | 13 |
Diagram
Pressure/Flow Rate Curve
Rod Kit
Lifting Disk
Tool Kit Specification
| Model | Capacity/Ton | Number of Jaws | Spread A/mm | Max Reach C/mm | Dimension B/mm | Dimension D/mm | Dimension E/mm | Dimension F/mm | Dimension G/mm | Hydraulic Cylinder | Stroke/mm | Weight/Kg |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| EHP-210 | 10 | 2 | 19-304 | 203 | 498 | 237 | 22 | 7.4 | 6.9 | HRC-106 | 152 | 12 |
| EHP-215 | 15 | 2 | 25-381 | 245 | 665 | 270 | 25 | 11.2 | 9.1 | HRC-1510 | 254 | 20 |
| EHP-225 | 25 | 2 | 63-457 | 304 | 846 | 348 | 31 | 12.9 | 9.7 | HRC-2514 | 362 | 43 |
| EHP-250 | 50 | 2 | 76-635 | 355 | 919 | 413 | 36 | 15 | 11.7 | HRC-5013 | 336 | 107 |
| EHP-310 | 10 | 3 | 19-304 | 203 | 498 | 237 | 22 | 7.4 | 6.9 | HRC-106 | 152 | 13 |
| EHP-315 | 15 | 3 | 25-381 | 245 | 665 | 270 | 25 | 11.2 | 9.1 | HRC-1510 | 254 | 21 |
| EHP-325 | 25 | 3 | 63-457 | 304 | 846 | 348 | 31 | 12.9 | 9.7 | HRC-2514 | 362 | 46 |
| EHP-350 | 50 | 3 | 76-635 | 355 | 919 | 413 | 36 | 15 | 11.7 | HRC-5013 | 336 | 110 |
Rod Kit Specification
| Puller Kit Model | EHP-210,EHP-215,EHP-310,EHP-315 | EHP-225,EHP-325 | EHP-250,EHP-350 |
|---|---|---|---|
| Screw Includes | Screw Dia X Length(mm) | Screw Dia X Length(mm) | Screw Dia X Length(mm) |
| Flat Head Screw | 25X25 | 38X57 | 51X70 |
| Flat Head Screw | 25X76 | 51X57 | 70X70 |
| Flat Head Screw | * | 51X102 | 70X120 |
| Taper Lead Screw | 25X25 | 38X64 | 51X95 |
| Taper Lead Screw | 25X76 | 51X64 | 70X95 |
| Taper Lead Screw | * | 51X114 | 70X140 |
| Screw Fitting | * | * | 71X45 |
Lifting Disk Specification
| Lifting Disk Model | Puller Model | Thickness(mm) | Diameter(mm) |
|---|---|---|---|
| EHP-2102 | EHP-210 | 6 | 153 |
| EHP-2102 | EHP-215 | 6 | 153 |
| EHP-2252 | EHP-225 | 6 | 153 |
| EHP-2502 | EHP-250 | 6 | 153 |
| EHP-3102 | EHP-310 | 10 | 203 |
| EHP-3102 | EHP-315 | 10 | 203 |
| EHP-3252 | EHP-325 | 10 | 254 |
| EHP-3502 | EHP-350 | 10 | 254 |
