EHP-215，2 Jaw,15 Ton, Safety-Cage Hydraulic Puller

The EHP Safety-Cage Hydraulic Puller Series from ULTPRE revolutionizes heavy-duty component removal with robust engineering and operator-focused design. Featuring a secure cage-style jaw structure, it ensures maximum safety by preventing component ejection during high-force operations.

PRICE ON REQUEST
Download Catalogue

Model: EHP-215 | Series: EPH | Product Line: Industrial Tools

Key Features:

  • Powerful hydraulic system enables effortless disassembly of large, stubborn parts.

  • One-person operation with enhanced efficiency for rapid pulling tasks.

  • Steel cage framework provides superior protection against flying debris.

  • Proportional control for smooth, precise force application.

Standard Configuration:
Includes pull rod kits and lifting discs for versatile adaptability across applications.

Ideal For:
Industrial maintenance, machinery repair, bearing removal, and gear disassembly in workshops, factories, or field operations.

Built to withstand extreme loads while prioritizing operator safety, the EHP series combines ULTPRE’s signature durability with intuitive functionality.

Maximum Operating Pressure (bar)700
Capacity(Ton)15
Number of Jaws2
Spread(mm)25-381
Max Reach(mm)245
Stroke(mm)254
Weight(Kg)20

Pressure/Flow Rate Curve

Rod Kit

Lifting Disk

ModelCapacity/TonNumber of JawsSpread A/mmMax Reach C/mmDimension B/mmDimension D/mmDimension E/mmDimension F/mmDimension G/mmHydraulic CylinderStroke/mmWeight/Kg
EHP-21010219-304203498237227.46.9HRC-10615212
EHP-21515225-3812456652702511.29.1HRC-151025420
EHP-22525263-4573048463483112.99.7HRC-251436243
EHP-25050276-635355919413361511.7HRC-5013336107
EHP-31010319-304203498237227.46.9HRC-10615213
EHP-31515325-3812456652702511.29.1HRC-151025421
EHP-32525363-4573048463483112.99.7HRC-251436246
EHP-35050376-635355919413361511.7HRC-5013336110
Puller Kit ModelEHP-210,EHP-215,EHP-310,EHP-315EHP-225,EHP-325EHP-250,EHP-350
Screw IncludesScrew Dia X Length(mm)Screw Dia X Length(mm)Screw Dia X Length(mm)
Flat Head Screw25X2538X5751X70
Flat Head Screw25X7651X5770X70
Flat Head Screw*51X10270X120
Taper Lead Screw25X2538X6451X95
Taper Lead Screw25X7651X6470X95
Taper Lead Screw*51X11470X140
Screw Fitting**71X45
Lifting Disk ModelPuller ModelThickness(mm)Diameter(mm)
EHP-2102EHP-2106153
EHP-2102EHP-2156153
EHP-2252EHP-2256153
EHP-2502EHP-2506153
EHP-3102EHP-31010203
EHP-3102EHP-31510203
EHP-3252EHP-32510254
EHP-3502EHP-35010254
